Mainboard Advance G41

Spesifikasi : Processor: Supports LGA 775 for Intel® Core™ 2 Duo, Pentium® Dual-Core processors, Supports Intel 45nm multi-core CPU Chipset: Intel® G41 & ICH7 Front Side Bus: 1333/ 1066/ 800MHz Memory: Dual channel DDR2 Max 4GB VGA on Die: Intel® GMA 4500 Expansion Slots: 1* PCIe x16 slot 1* PCIe x1 slot 2* PCI bus slots IDE: 1 * ATA 100 Serial ATA( SATA) / RAID: 2* SATAII Audio: 5.1 channel by Realtek LAN: Gigabit LAN by Realtek IEEE1394: N/ A Back Panel I/ O Ports: 1 x PS/ 2 keyboard port 1 x PS/ 2 mouse port 1 x VGA port 1 x Serial port 1 x Audio jack supports 3 jacks 4 x USB 2.0 ports 1 x RJ45 LAN port Internal I/ O Connectors: 1 x ATX 24-Pin power connector 1 x 4-pin ATX 12V power connector 2 x 4-pin CPU / System FAN connectors 1 x IDE connector 1 x Front Panel connector 1 x Intruder Alarm header 2 x USB 2.0 connectors support additional 4 ports 2 x Serial ATAII connectors 1 x S/ PDIF Out header 1 x Speaker header 1 x Front Audio header 1 x IrDA header BIOS Features: 8Mb flash EEPROM w/ LAN boot PnP, ACPI, WfM, DMI 2.0 Support CD: WHQL Drivers, Adobe Reader 7.07, Direct x 10.0, Norton 2006 Standards/ Manageability: PCI 2.3, USB2.0, DMI 2.5 Form Factor: Micro ATX ( 9.6" x 7.7" ) Hubungi segera: Deyu: 024-70552423, 085385097433, 08995717562 atau email: marketing@ komputer-computer.com
